前两天，公司同事在搞IHE测试的内容，在准备其中的两个测试ITI-11与ITI-12时，发现通过VS自带的WSDL命令是无法生成相应代码的。

其具体的WSDL内容，大家可以Google下面的内容来查找：
Appendix A: Web Service Definition for Retrieve Specific Information for Display and Retrieve Document for Display Transaction

经过一些尝试，发现：
1、该附录中，有两个WSDL文件，两个只差一行
2、两个文件格式都是错误的

这标准出的也太坑爹了吧。

具体修改方式如下：
1、字符集修改为utf-8
2、在文件最后，增加节点结束节点“definitions”
3、types节点增加前缀，变为“s:types”
4、所有的mime:content type=”text/html”，都修改为mime:content type=”text/xml”
然后就OK了

修改后的WSDL文件如下：

<?xml version="1.0" encoding="utf-8"?>
<definitions
  xmlns:http="http://schemas.xmlsoap.org/wsdl/http/"
	xmlns:s="http://www.w3.org/2001/XMLSchema"
	xmlns:s0="http://rsna.org/ihe/IHERetrieveForDisplay"
	xmlns:tm="http://microsoft.com/wsdl/mime/textMatching/"
	xmlns:mime="http://schemas.xmlsoap.org/wsdl/mime/"
	targetNamespace="http://rsna.org/ihe/IHERetrieveForDisplay"
	xmlns="http://schemas.xmlsoap.org/wsdl/">
 <!-- Defines the types available for the parameters -->
 <!-- May also include the return type definitions -->
	<s:types>
		<s:schema elementFormDefault="qualified" targetNamespace="http://rsna.org/ihe/IHERetrieveForDisplay">
 <!-- Add any items that control the returned values list or type here -->
 <!-- Add or remove items in the actual supplied WSDL to show the available types. -->
			<s:simpleType name="summaryRequestType">
				<s:restriction base="s:string">
					<s:enumeration value="SUMMARY" />
					<s:enumeration value="SUMMARY-RADIOLOGY" />
					<s:enumeration value="SUMMARY-CARDIOLOGY" />
					<s:enumeration value="SUMMARY-LABORATORY" />
					<s:enumeration value="SUMMARY-SURGERY" />
					<s:enumeration value="SUMMARY-EMERGENCY" />
					<s:enumeration value="SUMMARY-DISCHARGE" />
					<s:enumeration value="SUMMARY-ICU" />
					<s:enumeration value="SUMMARY-RX" />
				</s:restriction>
			</s:simpleType>

			<s:simpleType name="listRequestType">
				<s:restriction base="s:string">
					<s:enumeration value="LIST-ALLERGIES" />
					<s:enumeration value="LIST-MEDS" />
				</s:restriction>
			</s:simpleType>
 <!-- Please list all content types available, and remove those not available. -->
			<s:simpleType name="contentType">
				<s:restriction base="s:string">
					<s:enumeration value="text/html" />
				</s:restriction>
			</s:simpleType>

 <!-- Indicates that this item is a returned rows restriction -->
			<s:simpleType name="ReturnedResultCount" type="s:positiveInteger" />
 <!-- Please use the string "Search" as a prefix for all search criteria, and list below -->
 <!-- Indicates that this item is a search string -->
			<s:simpleType name="SearchString" type="s:string" />

		</s:schema>
	</s:types>
	<message name="RetrieveSummaryInfoHttpGetIn">
  <!-- Add other parameters here if they are available, using types defined above. -->
		<part name="requestType" type="summaryRequestType" />
		<part name="patientID" type="SearchString" />
		<part name="lowerDateTime" type="s:dateTime" />
		<part name="upperDateTime" type="s:dateTime" />
		<part name="mostRecentResults" type="ReturnedResultCount" />
	</message>
	<message name="RetrieveSummaryInfoHttpGetOut">
  <!-- If a complex type is defined for the return value, then it is suggested that -->
 <!-- it be used here instead of s0:string. If a complex type is allowed as one -->
 <!-- of the options, but an arbitrarily formatted string is also allowed, then create -->
 <!-- a union type here that allows either option. -->
		<part name="Body" element="s0:string" />
	</message>
	<message name="RetrieveListInfoHttpGetIn">
 <!-- Add other parameters here if they are available, using types defined above. -->
		<part name="requestType" type="listRequestType" />
		<part name="patientID" type="SearchString" />
	</message>
	<message name="RetrieveListInfoHttpGetOut">
 <!-- If a complex type is defined for the return value, then it is suggested that -->
  <!-- it be used here instead of s0:string. If a complex type is allowed as one -->
 <!-- of the options, but an arbitrarily formatted string is also allowed, then create -->
 <!-- a union type here that allows either option. -->
		<part name="Body" element="s0:string" />
	</message>
	<message name="RetrieveDocumentHttpGetIn">
 <!-- Add other parameters here if they are available, using types defined above. -->

 <!-- It is recommended that one of the sub-types of SearchUID is chosen here -->
 <!-- Especially if SearchStudyUID is allowed, then the display client can know that -->
  <!-- it is permissible to use a dicom uid here -->
		<part name="documentUID" type="SearchString" />
		<part name="contentType" type="contentType" />
	</message>
	<message name="RetrieveDocumentHttpGetOut">
 <!-- If a complex type is defined for the return value, then it is suggested that -->
 <!-- it be used here instead of s:string. If a complex type is allowed as one -->
  <!-- of the options, but an arbitrarily formatted string is also allowed, then create -->
 <!-- a union type here that allows either option. -->
		<part name="Body" element="s:string" />
	</message>

	<portType name="IHERetrieveForDisplayHttpGet">
		<operation name="RetrieveSummaryInfo">
			<input message="s0:RetrieveSummaryInfoHttpGetIn" />
			<output message="s0:RetrieveSummaryInfoHttpGetOut" />
		</operation>
		<operation name="RetrieveListInfo">

			<input message="s0:RetrieveListInfoHttpGetIn" />
			<output message="s0:RetrieveListInfoHttpGetOut" />
		</operation>
		<operation name="RetrieveDocument">
			<input message="s0:RetrieveDocumentHttpGetIn" />
			<output message="s0:RetrieveDocumentHttpGetOut" />
		</operation>
	</portType>

	<binding name="IHERetrieveForDisplayHttpGet" type="s0:IHERetrieveForDisplayHttpGet">
		<http:binding verb="GET" />
		<operation name="RetrieveSummaryInfo">
			<http:operation location="/IHERetrieveSummaryInfo" />
			<input>
				<http:urlEncoded />
			</input>
			<output>
        <mime:content type="text/xml" />
				<!--mime:content type="text/html" /-->
			</output>
		</operation>
		<operation name="RetrieveListInfo">
			<http:operation location="/IHERetrieveListInfo" />
			<input>
				<http:urlEncoded />
			</input>
			<output>
        <mime:content type="text/xml" />
				<!--mime:content type="text/html" /-->
			</output>
		</operation>

		<operation name="RetrieveDocument">
			<http:operation location="/IHERetrieveDocument" />
			<input>
				<http:urlEncoded />
			</input>
      <!-- The type of the output should be restricted on a per-server basis to the types -->
      <!-- actually provided. -->
			<output>
        <mime:content type="text/xml" />
				<!--mime:content type="text/html" />
				<mime:content type="application/x-hl7-cda-level-one+xml" />
				<mime:content type="application/pdf" />
				<mime:content type="image/jpeg" /-->
			</output>
		</operation>
	</binding>
 <!-- Bind the actual service here -->
	<service name="IHERetrieveForDisplay">

		<port name="IHERetrieveForDisplayHttpGet" binding="s0:IHERetrieveForDisplayHttpGet">
			<http:address location="http://localhost/" />
		</port>
	</service>
</definitions>
